2006-2007
电脑聚光/柔光灯
Spot/Wash light
技术参数
电压:AC110V/220V 50Hz/60Hz
灯泡:64756CP /93 220V/
1200W/HMI575W/HR
耗电量：1300W/680W
控制信号:DMX512
控制通道:3 CH
包装尺寸:535×405×315mm
净重:21kg
毛重:25kgc
TECHNICAL PARAMETER
Power:AC110V/220V50Hz/60Hz
Lamp:64756CP /93 220V/
1200W/HMI575W/HR
Power ：1300W/680W
Control signal:DMX512
Control Channels:3 CH
Size):535×405×315mm
N.W:21kg
G.W:25kg

性能特点
采用新型铝合金及压横钢板组合外形设计,美观大方
两个色彩轮,其中一个色彩轮有8个色彩,另一个有5个色
彩,可组合出32种色彩,彩虹效果, 频闪效果
电子线性无级调光; 控制回路3个.
快捷,准确,稳定,无声的换色系统,完全解决机械换色的缺点
二只轴流风扇致冷,内部优化风格设计,散热充分良好
内置过热保护
符合各种安全标准,IP20保护等级,电源线符合
CE20/22三级标准.
适用于演播厅,舞台及流动演出,时装表演等场合

PERFORMANCE TRAIT
Applying new type aluminum alloy and casting steel
plate shell design
Two color wheels,a color wheels have 8 colors and
a color wheels have 5 colors, achieving over 32 colors
Rainbow effect; Strobe effect
Mechanical linear infinite adjustment,Controling 3 loops
Fast,accurate,stable and noiseless color changing
system,best solution to mechanical color changing
2 convection cooling-fan,optimize internal air duct
way,heat elimination rapidely
Built-in over heat protection
According to various kinds of safety standards,
IP20 protect grades,The cable accords to the
CE20/22 standard
Suitable for studio,stage,performance and fashion
Performance
